Forklift Starters and Alternators - The starter motor nowadays is usually either a series-parallel wound direct current electric motor that has a starter solenoid, which is similar to a relay mounted on it, or it could be a permanent-magnet composition. Once current from the starting battery is applied to the solenoid, mainly via a key-operated switch, the solenoid engages a lever that pushes out the drive pinion that is situated on the driveshaft and meshes the pinion with the starter ring gear that is seen on the flywheel of the engine.
When the starter motor starts to turn, the solenoid closes the high-current contacts. When the engine has started, the solenoid consists of a key operated switch which opens the spring assembly to be able to pull the pinion gear away from the ring gear. This particular action causes the starter motor to stop. The starter's pinion is clutched to its driveshaft by an overrunning clutch. This permits the pinion to transmit drive in only one direction. Drive is transmitted in this particular manner via the pinion to the flywheel ring gear. The pinion remains engaged, like for example since the operator fails to release the key when the engine starts or if there is a short and the solenoid remains engaged. This actually causes the pinion to spin independently of its driveshaft.
This above mentioned action prevents the engine from driving the starter. This is an essential step since this type of back drive will enable the starter to spin very fast that it will fly apart. Unless adjustments were done, the sprag clutch arrangement will preclude using the starter as a generator if it was used in the hybrid scheme mentioned earlier. Typically an average starter motor is intended for intermittent use which would stop it being used as a generator.
The electrical parts are made to operate for around 30 seconds to be able to avoid overheating. Overheating is caused by a slow dissipation of heat is because of ohmic losses. The electrical components are intended to save weight and cost. This is really the reason most owner's manuals utilized for vehicles suggest the operator to pause for a minimum of ten seconds after every ten or fifteen seconds of cranking the engine, if trying to start an engine which does not turn over instantly.
The overrunning-clutch pinion was introduced onto the marked during the early 1960's. Before the 1960's, a Bendix drive was used. This drive system works on a helically cut driveshaft that consists of a starter drive pinion placed on it. When the starter motor begins turning, the inertia of the drive pinion assembly enables it to ride forward on the helix, thus engaging with the ring gear. When the engine starts, the backdrive caused from the ring gear allows the pinion to surpass the rotating speed of the starter. At this instant, the drive pinion is forced back down the helical shaft and therefore out of mesh with the ring gear.
In the 1930s, an intermediate development between the Bendix drive was made. The overrunning-clutch design that was developed and introduced during the 1960s was the Bendix Folo-Thru drive. The Folo-Thru drive has a latching mechanism together with a set of flyweights within the body of the drive unit. This was much better because the typical Bendix drive utilized in order to disengage from the ring as soon as the engine fired, even though it did not stay running.
The drive unit if force forward by inertia on the helical shaft when the starter motor is engaged and starts turning. Afterward the starter motor becomes latched into the engaged position. As soon as the drive unit is spun at a speed higher than what is achieved by the starter motor itself, for instance it is backdriven by the running engine, and after that the flyweights pull outward in a radial manner. This releases the latch and enables the overdriven drive unit to become spun out of engagement, thus unwanted starter disengagement could be avoided prior to a successful engine start.
